Wagner Tuning High-Performance Intercooler Kit Porsche 992 Carrera / Carrera S / Carrera GTS

Maximize the performance of your Porsche 992 with the Wagner Tuning High-Performance Intercooler Kit. This intercooler kit is specially developed for the 992-generation Carrera, Carrera S, and Carrera GTS and offers an impressive +88% more cooling capacity compared to the original intercooler.

Thanks to enlarged core dimensions of 2 x [300 x 256 x 115 mm], this intercooler delivers a total air volume of 17.7 liters – an 88% increase over OEM. The specially developed high-performance intercooler cores ensure optimal heat dissipation, while the free-form aluminum end tanks (CAD-designed) guarantee minimal back pressure and maximum efficient airflow.

With a tested pressure resistance level of 6 bar, this intercooler can withstand the toughest conditions. Additionally, the included four plastic air guides ensure optimal airflow to the intercooler, resulting in stable performance – both on the street and on the track.

The intercooler features a high-quality anti-corrosion coating, which not only provides protection but also further optimizes heat dissipation. The result: lower intake air temperatures, more power, and maximum reliability.

Key Advantages

• +88% more air volume – 17.7 liters instead of 9.4 liters OEM.

• +31% larger cooling surface – 1536 cm² instead of 1174 cm² OEM.

• Improved airflow and less back pressure – maximum efficiency and performance.

• Anti-corrosion coating – optimal protection and heat dissipation.

• Pressure resistant up to 6 bar – suitable for high loads and motorsport.

• Plug & Play installation – easy to mount as a replacement for the original intercooler.

• Suitable for street and track – tested according to the highest quality standards.

Specifications

• Part number: 200001196

• Suitable for:

  • Porsche 992.1 911 Carrera 283 kW / 385 hp (2019–)

  • Porsche 992.1 911 Carrera S 331 kW / 450 hp (2018–)

  • Porsche 992.1 911 Carrera GTS 353 kW / 480 hp (2021–)

• OEM intercooler: 2 x [273 x 215 x 80 mm] → V = 9.4 L, A = 1174 cm²

• Wagner intercooler: 2 x [300 x 256 x 115 mm] → V = 17.7 L (+88%), A = 1536 cm² (+31%)

• Pressure resistance: tested up to 6 bar

• Material: high-quality aluminum, CAD-designed end tanks

Why choose the Wagner Tuning Intercooler?

With the Wagner Tuning High-Performance Intercooler Kit, you elevate the performance of your Porsche 992 to a higher level. Lower intake temperatures ensure more power, less heat soak, and long-term stability – even under extreme loads. Thanks to its TÜV-certified quality and simple Plug & Play installation, this is the perfect upgrade for any 992 Carrera, Carrera S, or Carrera GTS driver who wants to get the most out of their car.
